Nimbus® Precision Balances

Nimbus® Precision Balances

Durable and reliable, Nimbus precision balances deliver a full breadth of readabilities ranging from 1mg to 0.1g. Innovative design enables a compact footprint, so it occupies minimal space but retains a high level of performance.

For science labs, the Nimbus balance offers 5 weighing applications including density determination, percentage weighing and dynamic weighing.

The Nimbus’ single-piece construction offers greater balance stability, producing highly repeatable results. The weighing sensor in the Nimbus is crafted from a single block, and contains fewer parts than a traditional force motor balance. This optimized internal mechanism is fabricated using hardened materials, helping the Nimbus tolerate rigorous laboratory use.

Nimbus balances are suitable for use in universities, medical laboratories and vets. For more information about the Nimbus precision balance, please contact us.

Key Specifications

Capacity
220g to 22000g
Readability
0.001g to 0.1g

Features and Benefits

Hardware

  • Color-coded keys facilitate quick recognition of the most frequently used buttons
  • Level indicator and adjustable feet ensure proper balance setup for optimum weighing results
  • Removable draft shield on models with 0.001g readability helps to reduce errors caused by air currents
  • Robust metal housing protects internal components in harsh environments
  • Sealed keypad protects against dirt and spills
  • USB and RS-232 interfaces provide speedy communication with computers and printers
  • Large, grade 304 stainless steel pan allows swift cleaning
  • Vivid, backlit LCD easily visible in any lighting conditions
  • Lockdown device to secure balance

Software

  • External calibration allows for verification and adjustment with weights
  • Printouts include date and time for data tracking within Good Laboratory Practices (GLP) guidelines
  • Selectable digital filtering helps minimize effects of vibration and disturbances
  • Zero-tracking feature ensures display returns to zero reading
  • Multilingual display permits use in various regions

Display

  • Vivid, backlit LCD easily visible in any lighting conditions

Power

  • AC adapter included

Models

Model Capacity Readability Pan Size Request a Quote
Picture of NBL 223eNBL 223e 220g 0.001g 4.7″ ø / 120mm ø
Picture of NBL 423eNBL 423e 420g 0.001g 4.7″ ø / 120mm ø
Picture of NBL 623eNBL 623e 620g 0.001g 6.3″ ø / 160mm ø
Picture of NBL 823eNBL 823e 820g 0.001g 6.3″ ø / 160mm ø
Picture of NBL 1602eNBL 1602e 1600g 0.01g 6.3″ ø / 160mm ø
Picture of NBL 2602eNBL 2602e 2600g 0.01g 6.3″ ø / 160mm ø
Picture of NBL 3602eNBL 3602e 3600g 0.01g 6.3″ ø / 160mm ø
Picture of NBL 4602eNBL 4602e 4600g 0.01g 6.3″ ø / 160mm ø
Picture of NBL 4201eNBL 4201e 4200g 0.1g 6.3″ ø / 160mm ø
Picture of NBL 6201eNBL 6201e 6200g 0.1g 6.3″ ø / 160mm ø
Picture of NBL 8201eNBL 8201e 8200g 0.1g 6.3″ ø / 160mm ø
Picture of NBL 12001eNBL 12001e 12000g 0.1g 15.7″x11.8″ / 400x300mm
Picture of NBL 16001eNBL 16001e 16000g 0.1g 15.7″x11.8″ / 400x300mm
Picture of NBL 22001eNBL 22001e 22000g 0.1g 15.7″x11.8″ / 400x300mm
Picture of NBL 223iNBL 223i 220g 0.001g 4.7″ ø / 120mm ø
Picture of NBL 423iNBL 423i 420g 0.001g 4.7″ ø / 120mm ø
Picture of NBL 623iNBL 623i 620g 0.001g 6.3″ ø / 160mm ø
Picture of NBL 823iNBL 823i 820g 0.001g 6.3″ ø / 160mm ø
Picture of NBL 1602iNBL 1602i 1600g 0.01g 6.3″ ø / 160mm ø
Picture of NBL 2602iNBL 2602i 2600g 0.01g 6.3″ ø / 160mm ø
Picture of NBL 3602iNBL 3602i 3600g 0.01g 6.3″ ø / 160mm ø
Picture of NBL 4602iNBL 4602i 4600g 0.01g 6.3″ ø / 160mm ø
