Nimbus® Analytical Balances

Nimbus analytical balances combine innovative design with a compact footprint, occupying minimal space whilst retaining a high level of performance. Suitable for advanced weighing in laboratories, universities, medical research and vets.

The Nimbus base is formed from a single piece of extruded aluminum, a material that provides superior temperature regulation. The single-piece construction offers greater stability, producing highly repeatable results. The weighing sensor in the Nimbus is crafted from a single block, and contains fewer parts than a traditional force motor balance. This optimized internal mechanism is fabricated using hardened materials, helping the Nimbus tolerate rigorous laboratory use.

For best results, we recommend using the Nimbus alongside our AVT anti-vibration table. For more information about the Nimbus analytical balance, please contact us.

Key Specifications

Capacity
80g to 250g
Readability
0.0001g

Features and Benefits

Hardware

  • Color-coded keys facilitate quick recognition of the most frequently used buttons
  • Level indicator and adjustable feet ensure proper balance setup for optimum weighing results
  • Robust metal housing protects internal components in harsh environments
  • Sealed keypad protects against dirt and spills
  • USB and RS-232 interfaces provide speedy communication with computers and printers
  • Large, grade 304 stainless steel pan allows swift cleaning
  • Vivid, backlit LCD easily visible in any lighting conditions
  • Lockdown device to secure balance

Software

  • External calibration allows for verification and adjustment with weights
  • Printouts include date and time for data tracking within Good Laboratory Practices (GLP) guidelines
  • Selectable digital filtering helps minimize effects of vibration and disturbances
  • Multilingual display permits use in various regions

Power

  • AC adapter included

Models

Model Capacity Readability Pan Size
Picture of NBL 84eNBL 84e 80g 0.0001g 3.5″ ø / 90mm ø
Picture of NBL 84iNBL 84i 80g 0.0001g 3.5″ ø / 90mm ø
Picture of NBL 124eNBL 124e 120g 0.0001g 3.5″ ø / 90mm ø
Picture of NBL 124iNBL 124i 120g 0.0001g 3.5″ ø / 90mm ø
Picture of NBL 164eNBL 164e 160g 0.0001g 3.5″ ø / 90mm ø
Picture of NBL 164iNBL 164i 160g 0.0001g 3.5″ ø / 90mm ø
Picture of NBL 214eNBL 214e 210g 0.0001g 3.5″ ø / 90mm ø
Picture of NBL 214iNBL 214i 210g 0.0001g 3.5″ ø / 90mm ø
