Eclipse® Precision Balances

With a capacitive touch keypad and one of the largest LCD readouts in the industry, Eclipse precision balances provide a unique weighing experience for lab professionals. The Eclipse’s Innovative design occupies minimal space on the lab bench yet offers a wide array of features perfect for advanced scientific weighing in laboratories, medical institutions and research labs.

Single-piece construction allows greater stability, enabling highly repeatable results. Containing fewer parts than a traditional force motor balance, the weighing sensor features an optimized internal mechanism, helping the Eclipse tolerate rigorous laboratory use.

For more information on the Eclipse range of precision balances, please contact us.

Key Specifications

Capacity
220g to 32000g
Readability
0.001g to 0.1g

Features and Benefits

Hardware

  • Large, grade 304 stainless steel pan allows swift cleaning
  • Overload protection helps prevent damage to internal components
  • Removable draft shield on models with 0.001g readability helps to reduce errors caused by air currents
  • Robust metal housing protects internal components in harsh environments
  • Sealed keypad protects against dirt and spills
  • USB and RS-232 interfaces provide speedy communication with computers and printers
  • Level indicator and adjustable feet ensure proper balance setup for optimum weighing results
  • The illuminated capacitive touch keypad provides responsive operation, and its durable, smooth surface can be easily wiped down

Software

  • External calibration allows for verification and adjustment with weights
  • Multilingual display permits use in various regions
  • Printouts include date and time for data tracking within Good Laboratory Practices (GLP) guidelines
  • Security password control prevents unauthorized access
  • Selectable digital filtering helps minimize effects of vibration and disturbances

Display

  • Vivid, backlit LCD easily visible in any lighting conditions
  • Capacity tracker built into display for easily monitoring possible overloads
  • Programmable backlight can be set to “always on,” “always off” or “light only when weighing”

Power

  • AC adapter included

Models

Model Capacity Readability
Picture of EBL 223eEBL 223e 220g 0.001g 4.7″ ø / 120mm ø
Picture of EBL 423eEBL 423e 420g 0.001g 4.7″ ø / 120mm ø
Picture of EBL 623eEBL 623e 620g 0.001g 6.3″ ø / 160mm ø
Picture of EBL 823eEBL 823e 820g 0.001g 6.3″ ø / 160mm ø
Picture of EBL 1602eEBL 1602e 1600g 0.01g 6.3″ ø / 160mm ø
Picture of EBL 2602eEBL 2602e 2600g 0.01g 6.3″ ø / 160mm ø
Picture of EBL 3602eEBL 3602e 3600g 0.01g 6.3″ ø / 160mm ø
Picture of EBL 4602eEBL 4602e 4600g 0.01g 6.3″ ø / 160mm ø
Picture of EBL 6202eEBL 6202e 6200g 0.01g 6.3″ ø / 160mm ø
Picture of EBL 4201eEBL 4201e 4200g 0.1g 6.3″ ø / 160mm ø
Picture of EBL 6201eEBL 6201e 6200g 0.1g 6.3″ ø / 160mm ø
Picture of EBL 8201eEBL 8201e 8200g 0.1g 6.3″ ø / 160mm ø
Picture of EBL 12001eEBL 12001e 12000g 0.1g 15.7″x11.8″ / 400x300mm
Picture of EBL 16001eEBL 16001e 16000g 0.1g 15.7″x11.8″ / 400x300mm
Picture of EBL 22001eEBL 22001e 22000g 0.1g 15.7″x11.8″ / 400x300mm
Picture of EBL 32001eEBL 32001e 32000g 0.1g 15.7″x11.8″ / 400x300mm
Picture of EBL 16001PEBL 16001P 16000g 0.1g 15.7″x11.8″ / 400x300mm
Picture of EBL 12001PEBL 12001P 12000g 0.1g 15.7″x11.8″ / 400x300mm
Picture of EBL 22001PEBL 22001P 22000g 0.1g 15.7″x11.8″ / 400x300mm
Picture of EBL 32001PEBL 32001P 32000g 0.1g 15.7″x11.8″ / 400x300mm
Picture of EBL 223iEBL 223i 220g 0.001g 4.7″ ø / 120mm ø
Picture of EBL 423iEBL 423i 420g 0.001g 4.7″ ø / 120mm ø
Picture of EBL 623iEBL 623i 620g 0.001g 6.3″ ø / 160mm ø
Picture of EBL 823iEBL 823i 820g 0.001g 6.3″ ø / 160mm ø
Picture of EBL 1602iEBL 1602i 1600g 0.01g 6.3″ ø / 160mm ø
Picture of EBL 2602iEBL 2602i 2600g 0.01g 6.3″ ø / 160mm ø
Picture of EBL 3602iEBL 3602i 3600g 0.01g 6.3″ ø / 160mm ø
Picture of EBL 4602iEBL 4602i 4600g 0.01g 6.3″ ø / 160mm ø
Picture of EBL 6202iEBL 6202i 6200g 0.01g 6.3″ ø / 160mm ø
